SYD-11143 Lubricating Oils Rust-Preventing Characteristics Tester
Summary:This instrument is designed and manufactured in accordance with the standards of GB/T 11143 Standard Test Method for the Anti-Rust Properties of Inhibitory Mineral Oils in the Presence of Water and ASTM D665 Standard Test Metho
SYD-11143 Lubricating Oils Rust-Preventing Characteristics Tester
Summary:
This instrument is designed and manufactured in accordance with the standards of GB/T 11143 "Standard Test Method for the Anti-Rust Properties of Inhibitory Mineral Oils in the Presence of Water" and ASTM D665 "Standard Test Method for the Anti-Rust Properties of Inhibitory Mineral Oils in the Presence of Water". . It is suitable for determining the ability of mineral oils (especially turbine oils) to inhibit rusting of ferrous parts when mixed with water and oil. It can also be used to measure other oils such as hydraulic oils, circulating oils and liquids heavier than water.
Main technical features:
1. Use digital temperature controller, heater and stirring motor to form a constant temperature bath. The temperature in the bath is uniform.
2. Equipped with a timer to control the test time and automatically time the test.
3. Equipped with four sample test holes. It can measure four samples simultaneously. High testing efficiency.
Main technical specifications:
Power supply | AC(220±10%)V, 50Hz |
Temperature range | 0℃～100℃ |
Temperature control accuracy | ±1℃ |
Temperature sensor | RTD, Pt100 |
Temperature display | Digital display |
Timing range | 1min～24hour, can be set at will |
Time display | Digital display |
Temperature control heating power | 600W |
Auxiliary heating power | 1000W |
Rotate speed of stirring motor | 1400RPM |
Sample stir rate | (1000±50)r/min |
Sample testing positions | Four positions |
Ambient temperature | (Room temp.～35)℃ |
Relative humidity | ≤85％ |
Maximum power consumption | 1800W |
Dimension | 580mm×320mm×600mm |
