WSC-2S Colorimeter

The colorimeter is a widely congested and easily operated colorimeter, which is suitable for measuring the reflected color of various objects, and can test the whiteness,chromaticity and color difference between two objects.Color touch screen with print

Send request
Ask for price

Characteristics

The colorimeter is a widely congested and easily operated colorimeter, which is suitable for measuring the reflected color of various objects, and can test the whiteness,chromaticity and color difference between two objects.

Color touch screen with printing output, upper computer output, U disk output, data storage,data check function.

This series of instruments can be widely used in textile, dye, printing and dyeing,paper making,building materials, enamel, food, printing etc.

Specifications

Parameters/Model

WSC-2S

Illuminant

0/d

Spectrum conditions

The overall response is equivalent to tri-stimulus values X, Y, and Z calculated in corresponding functions under CIE standard illuminant D65 and 10°view of field.

Color representations

Color: X, Y, Z; Y, x, y; L*, a*, b*; L, a, b; L*, U*, v*; L*, C*, h
Color difference：Δ E (L*a*b*); ΔE (L a b); ΔE (L*u*V*); ΔL*, ΔC*, ΔH*
White:
Ganz whiteness: Binary linear whiteness recommended by CIE．
(b) Blue-light whiteness: W＝B
(c) Tabble whiteness: It is recommended by ASTM (American Society for Testing and Mate
rials); W＝4B-3G
(d) Hunter whiteness: (GB/T 5950-1996) Wh=100-[(100-L)2+a2+b2]0.5
Yellow index: Yi=100(1.3013X-1.1498Z) (ASTM E 313)

Repeatability

s (Y) ≤0.3；s (x)，s (y) ≤0.001；ΔE(L*a*b*)≤0.2

Stability

Δh(Y)≤0.2

Display

7 inch color touch LCD

Interface

USB, U disk

Data storage

1000 sets

Power supply

220V ±22V，50Hz± 1Hz，30w

Overall dimensions

500mm×440mm×420mm

Weight (Gross)

9.5kg
