LBW-24NL High-flux freeze grinder
Freeze grinding instrument is an open, fast, efficient and high throughput grinding system for biological sample pretreatment. It has the functions of refrigeration and large capacity. It can process up to 24 samples at the same time, by matching differen
LBW-24NL High-flux freeze grinder
Freeze grinding instrument is an open, fast, efficient and high throughput grinding system for biological sample pretreatment. It has the functions of refrigeration and large capacity. It can process up to 24 samples at the same time, by matching different reagents, samples from various sources (including soil, plant and animal tissues/organs, bacteria, fungi, spores, paleontological specimens, etc.) can be broken up and homogenized to release DNA, RNA and protein of cells rapidly, for subsequent extraction and purification.
Product characteristics
▷ Save Time and effort
▷ Fast and easy
▷ High throughput sample
▷ The experiment was repeatable
▷ The sample is completely enclosed and free from cross-contamination
▷ LOW NOISE ≤55DB: Use brushless variable frequency motor
▷ No need to deal with liquid nitrogen operation, high safety
▷ Non-fragile parts design, electromagnetic locking protection
▷ Safety protection: Open cover and self-stop mode of grinding bin
▷ Stainless Steel Chamber, easy to clean and disinfect
▷ No regular maintenance is required
Main technical parameters:
Application | Tissue Homogenization, grinding, cell crushing, homogenization, material dispersion, preparation, sample mixing, Oscillation |
Process the sample size | 24*2ML/12*5ML/4*25ML /2*50ML Optional Two adapters |
Mode Cycle | According to the experimental parameters set, can be set in several good parameters between the continuous cycle, further reduce the interference of human factors |
DISPLAY | 7 inch rimless screen |
Refrigeration function | -50℃-0℃ adjustable |
Temperature control accuracy | 0.5 degree |
Open cover operation protection | Electromagnetic Lock |
Final discharging granularity | 5μm |
Number of grind platform | > 2 |
Homogeneity speed | 0 Fo 70hz/sec, working time: 0 S-9999 Min, user can set it by themselves |
Diameter of mill ball | 0.1-30mm |
Fixture stroke | 34mm (vertical) |
Adapter material | Aluminum, teflon or stainless steel, and agate, applicable to any material sample |
Accelerate | Reach the maximum speed within 2 seconds |
Speed cut | Reach the minimum speed within 2 seconds |
Noise level | ＜56db |
Grinding method | wet grinding, dry grinding or cryogenic grinding |
adaptop material | polytetrafluoroethylene steel |
