Qualitative Fungal Toxin Detector-HM-L01

Product Introduction:

This mycotoxin detector utilizes the principle of competitive inhibition immunochromatography. It analyzes the residues of mycotoxins in samples by detecting the binding of the analyte to an antibody. It can rapidly detect aflatoxin B1, zearalenone, vomitoxin, T2 toxin, ochratoxin, and fumonisin in grains, feed, cereals, edible oils, and condiments such as corn, rice, wheat, barley, brown rice, bran, paddy rice, soybean meal, rice bran, and feed.

Product Applications:

This mycotoxin detector is an integrated rapid detection and analysis device suitable for use in grain and oil systems, grain depots, grain and oil monitoring centers, grain and oil feed production and processing, food processing and trade, livestock and poultry farmers' self-inspection, and industrial and commercial quality supervision departments for rapid market screening, etc.

Product Advantages:

1. Overcurrent protection, short-circuit protection, and measurement voltage up to 10KV

2. Touchscreen design for parameter setting

3. Integrated shielding design between the measurement chamber and the main unit, significantly improving shielding effectiveness

4. Self-measurement of volume resistivity and surface resistivity of solid, liquid, and powder materials

5. Support for measurement of irregular sizes

6. Real-time printing of measurement results

7. Support for personalized customization

Product Performance:

1. Integrated portable rapid testing equipment. The chassis is made of industrial-grade ABS engineering plastic, making it easy to carry, sturdy and durable, meeting the needs of on-site and mobile testing.

2. Android intelligent operating system, featuring more efficient and user-friendly operation. The main control uses a multi-core processor, resulting in faster operation and stronger stability.

3. Automatically determines sample qualification, providing more intuitive test results. It can continuously test multiple samples, performing cyclic testing, allowing for immediate testing upon placement.

4. The instrument has a powerful built-in database with a menu library of various sample names, categorized management, and flexible selection of test samples, test indicators, testing units, etc. Users can edit and enter sample names, test indicators, submitting units, etc., add or delete names, and save them to the sample database.

6. The instrument has Wi-Fi networking and 4G/GPRS remote transmission capabilities. It can accept a SIM card for remote data transmission, quickly uploading data to a computer and server monitoring platform for data

management and statistics.

7. High level of intelligence; the instrument has self-testing functions: it features power-on self-testing and zeroing functions, and automatic repeatability testing.

8. New generation high-speed thermal printer; automatically prints test reports and QR codes upon completion of testing. The printed report includes the tested substance, pass/fail status, testing unit, inspected unit, inspector, and testing time.

9. The instrument has a monitoring platform; data can be uploaded via LAN and the internet, and test results are directly transmitted to the food safety monitoring platform. This enables regional food safety monitoring, big data analysis and processing, and data statistics, monitoring the short- and long-term dynamics of regional food safety, achieving food safety problem prediction and early warning.

10. It can perform all testing items under the same software, and the test results can be displayed intuitively through a single window.

11. Immunochromatographic detection module: track-type automatic transmission scanning; the test card automatically exits after testing.

12. Automatic CT line recognition; no manual adjustment required.

13. Simple and labor-saving sample processing; overall operation is fast, safe, and convenient.

14. High sensitivity, high detection accuracy, high repeatability, and a scanning high-precision optical sensor.

15. The instrument has self-protection functions, allowing users to set usernames and passwords to prevent unauthorized operation.

16. The instrument has recalibration, locking, and factory reset functions.

17. Supports USB flash drive storage. Result judgment lines can be modified, and control and calibration values can be saved; data is not lost in the event of a power outage.

18. Compatible with all detection cards on the market, with no restrictions on consumables, greatly enhancing the user experience.

Key Parameters:

1. Main control chip uses an ARM Cortex-A7, RK3288/4-core processor with a 1.88GHz clock speed, resulting in faster operation and stronger stability.

2. Display: 7-inch LCD touchscreen display with a user-friendly Chinese interface for intuitive and simple readings.

3. AC/DC dual-use, DC 12V power supply, can be connected to a vehicle power supply, and can be equipped with a 6Ah high-capacity rechargeable lithium battery for convenient outdoor mobile testing.

4. Automatic adjustment and calibration of light source brightness.

5. Intelligent constant current and voltage regulation, automatic light intensity calibration, and no temperature drift during long-term continuous operation.

6. Built-in new national limit standards for on-site comparison with test results, with continuous standard updates.

7. Continuous sample injection and continuous testing.

8. Automatic sample number accumulation.

9. Expandable testing items.

10. Batch printing and uploading of test results.

11. Test results are in Excel spreadsheet format, which can be copied by connecting to a computer. 12. Detection result storage capacity: 200,000 records

13. Standard USB interface, driver-free installation.

14. Firmware upgradeable.

Technical Parameters:

Fungal Toxin Quantitative Analyzer Configuration List:
