RTOP-268Y Plant Chamber
RTOP is a biological incubation experimentation instrument, which adopts microcomputer automatic control system, programmable control mode, and intermitting cooling.By setting the multiple parameters, it is able to mimic a natural environment. It has
RTOP-268Y Plant Chamber
Introduction
RTOP is a biological incubation experimentation instrument, which adopts microcomputer automatic control system, programmable control mode, and intermitting cooling.
By setting the multiple parameters, it is able to mimic a natural environment. It has illumination, temperature-constant day and night shift automatically functioning. It is able to meet various biological incubation tests.
Our incubator is able to apply to various areas such as seed germinate & breeding, plant group foster and planting, animalcule incubation, breeding of insects and small animals, anti-oxidation experiment of medicines and environmental experiments of articles; and it is especially
applicable for the study of Bioengineering, Medical study, agricultural, Aquatic, Animal husbandry etc.
Features
LCD screen display, simple operation, accurate control, easy to view at night.
The interior features a stainless steel design.
The program can be controlled by gradient such as time, temperature and illumination.
Over-temperature and sensor abnormality protection to ensure the equipment and sample safety.
With sterilization function, sets sterilization time, and automatically turns off sterilization function at the end of sterilization time.
A power-down protection, boot display after the state power of money, there are storage memory.
Light source adopts LED light source suitable for plant growth, low energy consumption, low heat.
Inside the incubator is grid structure, which can be adjusted as the sample’s length, it is very convenient and practical.
Optional capacity: 268L, 310L, 400L,500L, 1000L
Technical parameter
Temperature range | 0-50°C |
Temperature fluctuation | ±0.5°C |
Temperature uniformity | ± 1°C |
Humidity range | 50-90% |
Humidity fluctuation | ±7%RH |
Illuminance | 0~8000lux (light can be customized) Can increase the light intensity according to customer requirements |
Heating power | 300W(GTOP-1000:700W) |
Compressor power | 190W-320W |
Compressor delay guard time | about 3min |
Noise | <70Db |
Working mode | continuous operation (compressor intermittent working) |
Working environment | Temperature: 0-38°C, humidity<80%RH, Non-corrosiveness gas |
Power | 220±22V, 50±0.5HZ |
Model |
Volume |
External Size(L*W*H) |
Inner Size(L*W*H) |
Temp range |
Light degree |
RTOP-268Y | 268L | 580*630*1755 mm | 480*480*1040mm | 0~50℃ | 0~8000LUX |
RTOP-310Y | 310L | 580*630*1895 mm | 480*480*1290mm | 0~50℃ | 0~8000LUX |
RTOP-400Y | 400L | 744*658*1760mm | 570*585*996mm | 0~50℃ | 0~8000LUX |
RTOP-500Y | 500L | 705*825*1971 mm | 575*650*1480mm | 0~50℃ | 0~8000LUX |
RTOP-1000Y |
1000L |
1230*708*1865 mm |
1110*578*1375mm |
0~50℃ |
0~12000LUX |
