CON-810-Portable Conductivity Analyzer (Supports TDS/Salinity/Temperature Testing)
Product Overview
Conductivity is an important indicator of the ability of electrolytes in a solution to conduct electricity, reflecting the concentration and types of ions present. The measured values are used to assess the purity and pollution levels of water, helping to determine whether the water has been contaminated by electrolytes. Our product not only provides users with accurate and reliable measurement results but also offers strong technical support for water quality management and environmental protection
Technical Specifications
Measuring item | Value | |
Conductivity | Measuring range | 0.0uS/cm～100.0mS/cm |
Accuracy | 0.1uS/cm | |
Indication error | ±1.0% (F.S) | |
TDS | Measuring range | 0.0mg/L～64000.0mg/L |
Accuracy | 0.1mg/L | |
Indication error | ±0.5% (F.S) | |
Salinity | Measuring range | 0mg/L～5000mg/L |
Accuracy | 0.1mg/L | |
Indication error | ±1.0% (F.S) | |
Temperature | Measuring range | 0℃ ~50.0℃ |
Accuracy | 0.1℃ | |
Indication error | ±0.5℃ | |
Testing standard | GB/T 13580.3-1992 | |
Analytical method | Electrochemical method | |
Electrode | High precision industrial grade conductive electrode | |
Input impedance | ≥1×1012Ω | |
Display | 2.4inch 240*160 LCD | |
Data storage | Can store 300 set of data records | |
Charging/Data interface | Type C | |
Dimension | 185mm×92mm×50mm | |
Weight | About 0.55kg | |
Working environment | (1) Ambient temperature: 5~40℃ ⑵ Relative humidity: ≤85% ⑶ Power supply: Rechargeable lithium battery or AC (220±22)V (50±0.5) Hz (4) No significant vibration and electromagnetic interference, avoid direct sunlight. | |
Functional Features：
1.The measurement process is controlled by a microcontroller unit (MCU) with digital filtering technology to enhance system reliability.
2.Simultaneous measurement of conductivity and temperature for efficient reading.
3.Equipped with a high-performance, ultra-low-power microcontroller and a high-capacity rechargeable lithium battery to ensure extended instrument runtime.
4.Data protection against blackout condition ensures that data is not lost during a power outage.
5.Storage capacity for 999 data sets with time tags, supporting data protection during power loss and data transfer to a computer for easy record-keeping and analysis.
6.Auto-lock mode: The display automatically locks onto stable readings.
7.Equipped with an LCD large screen display for intuitive and convenient operation, supporting one-handed operation and suitable for various usage scenarios.
8.The instrument is designed with corrosion resistance, waterproofing, and dustproofing to adapt to a variety of harsh environments.
