WGZ-4000/WGZ-2000/WGZ-1000/WGZ-500/WGZ-200/WGZ-100Ratio Turbidimeter

Measurement of light scatter and decay of the insoluble particles suspended in water or transparent liquids.Automatic range switching, and multi point calibration.Equipped with average measurement function.Compliant with GLP Regulation and ISO 7027.

Send request

Ask for price

Characteristics

Measurement of light scatter and decay of the insoluble particles suspended in water or transparent liquids.

Automatic range switching, and multi point calibration.

Equipped with average measurement function.

Compliant with GLP Regulation and ISO 7027.

Quantitative analysis of particle contents.

Specifications

Parameters/Mode	WGZ-4000	WGZ-2000			WGZ-1000	WGZ-500			WGZ-200	WGZ-100
Light source	Tungsten halogen lamp (6V / 10W)
Wavelength	400nm-600nm
Measurement mode	NTU, FTU, EBC, ASBC
Measurement range NTU	0.000-50.00; 50.01-200.0; 200.1-2000; 2000.1-4000	0.000-50.00; 50.01-200; 200.1-2000			0.000-50.00; 50.01-200; 200.1-1000	0.000-50.00; 50.01-200; 200.1-500			0.000-50.00; 50.01-200.0	0.000-50.00; 50.01-100.0
Minimum reading	0.001
Allowable error of indication	≤±6%
Zero Drift	≤±0.3%FS
Stability of indication	≤±1%FS
Repeatability	≤0.5%
Sample bottle	Φ 25 mm×95 mm
Sample volume	30--40 ml
Calibration points	7		6	5			4	3			3
Display	LCD Touch Screen
Interface	USB、U disk
Data storage	1000 sets
Power supply	220V±22V，50Hz±1Hz，30w
Overall dimensions	430mm×430mm×300mm
Weight (Gross)	9kg
