RE-52A/RE-52C/RE-5299 1L Automatic mini type rotary evaporator
USES:Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when
1L Automatic mini type rotary evaporator
USES:
Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when they do extraction and concentration .
Features:
Motor has the function of 10-120 RPM stepless speed regulation and automatic lifting , revolving consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-120 RPM range, it has reached the advanced level at home and abroad.
1 Quick and easy lifting mechanism
2 Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3 Vertical condensation system of high rate of evaporation
4 Vacuum sealing way
5 Automatic control temperature digital display
RE-52A/RE-52C/RE-5299 1L
Model | RE-52A | RE-52C | RE-5299 | |
Glass meterial | GG-17 | |||
Holder material | Aluminium alloy | |||
Pot shell Material | Aluminium alloy 250*365*150mm | Aluminium alloy 250*365*150mm | Aluminium alloy 265*310*80mm | |
Pot bravery | Stainless steel 240*120mm | Stainless steel 250*130mm | Stainless steel 250*140mm | |
Evaporator flask | 1L 24# | |||
Collect flask | 0.5L 24# | |||
Vacuum degree | 0.098Mpa | |||
Rotary speed | 0-120rpm | |||
Rotary power | 30W | |||
Heating power | 1KW | |||
Heating temp. | 0-99C | |||
Temp. accuracy | -1 | |||
Lifting power | --- | 15W | ||
Lifting stroke | 120mm | |||
Voltage | 220/110V 50/60HZ | |||
Dimension | 700*440*1005mm | |||
Packing size | 590*460*460mm | |||
Packing weight | 21kg | |||
Configuration list | ||||
Speed mode | Electronic stepless | |||
Temp. display | Digital | |||
Temp. control | Intelligent temp. control | |||
Sealing method | PTFE | |||
Condenser | Vertical 85*460mm 29# | |||
Lifting mode | Manual lifting | Electric automatic lifting | Electric automatic lifting | |
Continuous feed | Standard mouth feed valve | 19# Standard mouth feed valve | 19# Standard mouth feed valve | |
Option | ||||
Splash device | Transparent cover for heating bath | |||
Bath temp.range | 0-400C |
