CS-300 SE CS-380 SE CS-300S SE High Precision Gloss Meter

CS-300 SE CS-380 SE CS-300S SE High Precision Gloss Meter100000 ultra long endurance cyclesModel differentia

Send request

100000 ultra long endurance cycles

Model differentiation table

Model	CS-300 SE（Single angle）	CS-380 SE（Triangle angle）	CS-300S SE（Single angle，Small aperture）
Measuring Angle	60°	20°、60°、85°	60°
Electricity level	Fully charged, can be used 100000 times	Fully charged, can be used 60000 times	Fully charged, can be used 100000 times
Measuring range	0-200GU	20°:0-200GU 60°:0-200GU 85°:0-100GU	0-200GU
Measuring light spots	9*15mm	20°:1010mm 60°:915mm 85°:5*38mm	2*3mm（Small aperture）
Display resolution	0.1GU	0-100:0.1GU;大于100:1GU
Repetitive accuracy	0-100GU:0.2GU 100-200GU:0.2%GU
Measuring time	＜1s	＜1.5s	＜1s

Technical parameter

Model	CS-300 SE	CS-380 SE	CS-300S SE
Measuring Angle	60°	20°、60°、85°	60°
Measuring light spots(mm)	60°:9*15	20°:1010；60°:915；85°:5*38	60°:2*3
Measuring range	60°:0-200GU	20°:0-200GU;60°:0-200GU; 85°:0-100GU	60°:0-200GU
Display resolution	0.1GU	0-100:0.1GU;大于100:1GU
Measurement repeatability accuracy※	0-100GU:0.2GU；100-200GU:0.2%GU
Measurement mode	Simple mode and statistical mode
Measurement accuracy	Meet the requirements of JJG 696-2015
Measurement time	＜1s	＜1.5s	＜1s
Data storage	5000 pieces of data
Volume	1655177mm(LWH)
Weight	400g
Language	Chinese，English
Battery capacity	3000mAh lithium battery
Electricity level※※	Fully charged, can be used 100000 times	Fully charged, can be used 60000 times	Fully charged, can be used 100000 times
Interface	Type-C
Screen size	2.4 inches（Screen resolution320*240）
Computer software	Yes
Working temperature	0-40℃
Working humidity	Less than 85%, no condensation
Accessory	5V/2A charging head, data cable, manual, USB flash drive (upper computer software), calibration standard board, third-party calibration certificate
Purpose	Paint and ink, coatings, electroplating, plastic electronics, hardware and other fields
