TD4C Portable Low Speed Centrifuge
Widely used in laboratory, hospital and etc...
TD4C Portable Low Speed Centrifuge
(Max speed: 4000rpm .Max volume:8x20ml)
Features
1. Widely used in laboratory, hospital and etc...
2. Brushless motor for model TD4C, free maintenance, no powder pollution, quick in speed up and down.
3. Range of speed from 0 to 4000rpm, smooth in operation, low noise and small vibration.
4. Micro computer control system, digital display the RCF, time and speed.
5. Electric cover lock, compact design, super speed and imbalance protection.
6. With over speed and imbalance protection.
TD4C Technical Parameter：
Max. Speed | 4000rpm |
Max. RCF | 1880×g |
Max. Capacity | 8×20ml |
Time Range | 0~99min |
RPM/RCF Convert | Yes |
Noise (dB) | ≤ 55 |
Temperature | Normal |
Acc/Dec | 10 Kinds |
Speed Accuracy | ±20r/min |
Temperature Accuracy | / |
Voltage(V/Hz) | AC 220V/110V 50HZ/60HZ |
Size (W x D x Hmm) | 310×270×220mm |
Net Weight(Kg) | 7.5KG |
Certificates | CE,ISO & Calibration report are available |
Matched Rotors for TD4C
Order No. | Rotor Type | Max Speed (rpm) | Max Volume (ml) | Max RCF (g) |
NO31701 | Angle Rotor | 4000 | 8×15ml/20ml | 1800 |
NO31702 | Angle Rotor | 4000 | 6×10ml/15ml/20ml | 1880 |
NO31703 | Angle Rotor | 4000 | 12×5ml | 1540 |
NO31704 | Angle Rotor | 4000 | 12×7ml | 1540 |
NO31705 | Angle Rotor | 4000 | 8x10ml vacuum tube | 1800 |
8x5ml vacuum tube adapter | 1800 | |||
8x7ml vacuum tube adapter | 1800 |
