SYD-12579 Foaming Characteristic Tester
Summary: The instrument is designed and manufactured in accordance with GB/T12579 Determination of Lubricating Oil Foam Characteristics and ASTM D 892 Standard Test Method for Lubricating Oil Foam Characteristics. For determinin
SYD-12579 Foaming Characteristic Tester
Summary:
The instrument is designed and manufactured in accordance with GB/T12579 "Determination of Lubricating Oil Foam Characteristics" and ASTM D 892 "Standard Test Method for Lubricating Oil Foam Characteristics". For determining the foaming tendency and stability of lubricating oils.
Main technical features:
1. The instrument adopts an integrated structure. It includes three parts: low-temperature test part and its control, high-temperature test part and its control, and portable cooler for the low-temperature test part.
2. The temperature controller has parameter modification function. If there is a deviation between the displayed temperature and the test temperature, this function can be used to correct it.
3. The instrument has automatic timing alarm function.
Main technical specifications:
Power supply | AC(220±10%)V, 50Hz |
Total power consumption | ≤2700W |
Air flow rate | (94±5)ml/min,adjustable |
Temperature control range for high temperature bath | (Room temp.~99.9)℃ |
Temperature control range for low temperature bath | (5~99.9)℃ |
Temperature control accuracy | ±0.5℃ |
Timer | 5min and 10min，accurate to second |
Ambient temperature | (15~35)℃ |
Relative humidity | ≤85% |
Dimension | Main unit：690mm×460mm×700mm |
Cooler：400mm×450mm×300mm | |
Net weight | 48kg |
